Hydraulic Press Radius Adjustable Roof Curving Machine Crimping Steel Roof

Large Image : Hydraulic Press Radius Adjustable Roof Curving Machine Crimping Steel Roof

Product Details:

Place of Origin:	Cangzhou, China
Brand Name:	SHITONG
Certification:	ISO,CE
Model Number:	T 1000

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Contact us get the best price
Packaging Details:	Loading container
Delivery Time:	35 days
Payment Terms:	L/C,T/T
Supply Ability:	20 sets/month

Contact Now

Detailed Product Description

Name:	Roof Sheet Curving Machine	Machine Color:	Blue And Orange
Drive Method:	1" Chain	Working Speed:	0-3 M/min
Maching Weight:	1000 KG	Control System:	PLC
Material Of Blade:	Cr12 Heat Treatment	Cutting Mode:	None Stop Cutting
Rows Of Rollers:	12 Stations
Highlight:	hydraulic press roof curving machine , adjustable radius roof crimping machine , steel roof curving machine with warranty

Hydraulic Press Radius Adjustable Roof Curving Machine Crimping Steel Roof

Product Overview & Core Advantages

This Hydraulic Press Radius Adjustable Roof Curving Machine is specialized in crimping and shaping steel roof panels into curved/arched profiles, ideal for residential, commercial, and industrial roofing projects that require flexible design and structural stability.

Cost-Effective Design: Optimized mechanical structure reduces manufacturing and maintenance costs.
Stable Feeding System: Equipped with 3-5 feeding shafts that guide roof panels smoothly.
Adjustable Arch Radius: The arch radius can be freely set and modified via the PLC control system.
Compact & Easy to Operate: Small footprint with intuitive PLC + touch screen control.

Detailed Technical Parameters

Parameter Category	Specifications
Suitable Material	Steel, galvanized steel
Material Thickness	0.5-1 mm
Roller Material	High-grade 45# forged steel (surface hard chromium plating)
Roller Rows/Stations	3-5 stations
Shaft Material	High-grade 45# forged steel
Shaft Diameter	50mm
Cutting Blade Material	Cr12 steel (heat-treated)
Cutting Mode	Non-stop cutting
Operating Speed	0-3 m/min (adjustable)
Side Plate Thickness	16mm
Total Power	3 KW
Voltage	380V 50HZ 3Phase
Appearance Size (Approx.)	2000mm1400mm1500mm
Weight (Approx.)	1 ton
Electronic Control System	PLC + Touch Screen

Logistics & Cooperation Terms

Packing & Transportation

Main machine wrapped with thick, moisture-proof plastic film
Vulnerable components padded with foam
All machines can be loaded into one 40-foot container

Payment & Delivery

Term Type	Details
Payment Term	30% deposit via T/T in advance, 70% balance via T/T after inspection
Delivery Time	40 days after receiving deposit

Warranty & After-Sales Service

Warranty Period: 2 years for entire machine
Lifelong Technical Support: Includes spare parts at cost price, free online guidance, optional on-site service

Company Product Range

We are a professional manufacturer of metal processing and roll forming equipment, offering:

Roofing & Cladding Equipment
Structural Steel Equipment
Pipe & Tube Equipment
Auxiliary Metal Processing Equipment

One-stop supply capability for complete metal processing solutions.
