Product Details:
Payment & Shipping Terms:
|
Thickness: | 0.3mm-0.8mm | Coil Width: | 1000mm |
---|---|---|---|
Shaft Diameter: | 70 Mm | Roller Material: | High Grade NO. 45 Forged Steel With 0.05mm Hard Chrome Plating |
Shaft Material: | High Grade NO. 45 Carbon Wrought Steel | Tile Type: | Colored Glaze Steel |
Name: | Sheet Metal Roll Forming Machines | Weight: | 3.5T |
Speed: | 20m/min | Color: | Blue |
Highlight: | PPGL metal roofing roll forming machine,PPGI metal roofing roll forming machine,PPGI steel roll forming machine |
Zinc Colored Steel Metal Roof Rollforming Roof Sheet Machine
Technical parameters:
Suitable Material | Material | GI, PPGI, PPGL |
Width | 1200 mm | |
Thickness | 0.3-0.8 mm | |
Material of rollers | High grade 45# forged steel, surface hard chromium plating | |
Rows of rollers | 15 stations | |
Material of shafts | High grade 45# forged steel | |
Diameter of shafts | 70 mm | |
Material of cutting blade | Cr12 Heat Treatment | |
Cutting Mode | Hydraulic Guide Column | |
Speed | 20 m/min | |
Side plate thickness | 16 mm | |
Chain size | 1 inch | |
Total power | 4 kw | |
Voltage | 380V 50HZ 3Phase | |
Appearance size (About) | 7500mm*1800mm*1400mm | |
Weight(About) | 4.5 tons | |
Length measurement | Encoder | |
Control mode | Delta PLC | |
Operating mode | Button + Touch screen |
Product
We also produce...
All kinds of color steel forming machine, Double layer roll forming machine, C&Z purlin roll forming machinery, Floor deck roll forming machine, Steel frame roll forming machine, Roll shutter door roll forming machine, Sandwich panel roll forming machine, Highway guardrail forming machine and other cold roll forming machines.
If you are interested in other machines, please contact me .
Packing Method
Main machine is packaged with plastic film
Transportation
All machines need one 40 feet container to hold
Payment Term
30% deposit by T/T in advance and 70% balance after inspection confirmation before shipment.
Delivery Time
Within 35 days after receiving deposit.
Warranty
Two years, and we will provide technical support for wholelife of the equipment.
If some parts of machine broken within 2 year, we will give customer the spare parts for free. (include chain, bearing, roller,oil pipe, counting wheel) If more than 2 year, maybe some spare parts need to be charged. If machine can not work well, we can teach them online until the machine is perfect. If you need, we can go to your place to assist you. But you need to provide the cost of the engineer.
